Description
The MRCOOL GeoCool GCHPD024TGTANDR is a 24,000 BTU (2-ton) downflow geothermal heat pump with a two-stage compressor and a built-in desuperheater, designed with a downflow blower orientation for installation in attics.
Highlights
- Downflow blower orientation, ideal for attic installation
- Two-stage compressor uses only the energy needed to heat or cool, rather than running at full load continuously
- Built-in desuperheater improves overall efficiency by recovering waste heat from the compressor
- ETL, ENERGY STAR, and AHRI certified
- Insulated, sloped stainless steel drain pan
- Advanced unit control board with diagnostic LEDs for easy troubleshooting
- Double O-ring water connections for easy service access
- Optional domestic water pre-heating capability
- Made in the USA; may qualify for federal tax credits and other incentives
Details
Avermont Direct is an authorized MRCOOL dealer. This GeoCool downflow heat pump draws on the stable temperature of the ground or a water source to heat and cool the home rather than relying on outside air, which lets a two-stage compressor run efficiently instead of cycling at full load. Base warranty: 5-year limited parts; when registered, coverage extends to a 10-year limited parts warranty and a 10-year compressor warranty. It's sized for homes with a coverage need around 1,000 sq. ft., and installation by a licensed HVAC professional is required for the warranty to apply.
Need Help?
If you have questions about this product before you order, our team is happy to help.
Email: support@avermontdirect.com
Phone: +1 (844) 455-3695
Hours: Monday–Friday, 9AM–5PM
Live Chat: Available 24/7
| Configuration | Downflow, Right Return with Desuperheater |
| Dimensions | 25¾" W x 56" H x 32" D |
| Tonnage | 2 Ton |
| Cooling Capacity | Ground Water 23,000–29,000 / Ground Loop 21,900–27,000 BTU/h |
| Heating Capacity | Ground Water 19,000–25,700 / Ground Loop 16,500–18,500 BTU/h |
| EER (Full Load) | Ground Water 27.40 / Ground Loop 17.95 |
| EER (Part Load) | Ground Water 36.50 / Ground Loop 25.93 |
| Voltage | 230V |
| Max Coverage Area | 1,000 sq. ft. |
| Certifications | ETL Listed, ENERGY STAR Certified, AHRI Certified |
| Warranty | 5-year limited parts (base); 10-year limited parts & 10-year compressor when registered |
